Item # bci1726155

The Craftmade LW52BN has been discontinued

** See similar or replacement items below **

Craftmade Leeward 52" 5 Blade Indoor / Outdoor Ceiling Fan - Requires Blade Selection

Model: LW52BN

from the Leeward Collection
Discontinued
We still have product details and accessories, scroll down to see them!

Product Overview

This product has additional required/recommended options. To configure, add to your cart.

  • Down Rods
    Down Rods Recommended
  • Fan Blades
    Fan Blades Recommended
  • Light Kit
    Light Kit Recommended



A simple, uncluttered look makes Leeward an equally discerning choice for a transitional look.

Features:

  • Standard, 3-Speed Reversible Motor
  • Limited Lifetime Warranty
  • Pull Chain Control
  • Damp Location Rated

Blade Specifications:

  • Blade Span: 52"
  • Number of Blades: 5
  • Blade Pitch: 12°
  • Blades Included: No

Motor Specifications:

  • Motor Type: AC Induction
  • 153mm x 12mm
  • Reversible Motor: Yes
  • CFM (High): 4737
  • RPM (High): 174
  • Voltage: 120 V

Sloped Ceiling Specifications:

  • For ceilings with slope from 35° to 45°, use the 45AD angled ceiling adapter

High or Low Ceiling Specifications:

  • The Leeward is designed for installation on standard 8 to 9 foot ceilings. If your ceiling is higher, you'll need to purchase an additional downrod. The rule of thumb is that ceiling fans should have a minimum of 7 feet and a maximum of 9 feet of clearance between the bottom of the fan and the floor in order to circulate air efficiently. If you have a low ceiling, purchase the CMA flush mount adapter to reduce the hanging height of your fan.

Suggested Downrod Lengths:

  • 9 Foot Ceiling: 6" - 12"
  • 10 Foot Ceiling: 12" - 18"
  • 11 Foot Ceiling: 18" - 24"
  • 12 Foot Ceiling: 24" - 36"
  • 13 Foot Ceiling: 36" - 48"
  • 14 Foot Ceiling: 48" - 60"
  • 15 Foot Ceiling: 60" - 72"
  • For ceiling heights greater than 15 feet, you'll need to purchase the downrod Coupler to join two downrods together.

This product is listed under the following manufacturer number(s):


*Denotes a finish or option that has been discontinued.

Dimensions and Measurements

Blade Pitch
12 Degrees
Blade Span
52 in.
CFM (High)
4737
Downrod Size(s)
6 in.
Height
14.3 in.
Motor Size
153 mm
Width
52 in.

Included Components

Blades Included
Yes
Blades Sold Separately
No
Controller Included
No
Downrod(s) Included
Yes
Light Kit Included
No

Characteristics and Features

Base Color
White, Nickel, Bronze
Blade Finish
Nickel, White, Bronze
Bulb Visible
No
Control Type
Pull Chain
Fan Type
Hanging
Light Kit Compatible
Yes
Motor
AC Induction
Number of Blades
5
Reversible Motor
Yes
Style
Transitional
Theme
Transitional, Nautical

Electrical and Operational Information

Energy Efficiency (CFM / Watt)
73
Power Source
Hardwired
RPM (High)
174
RPM (Low)
74
Speeds
3
Voltage
120
Wattage
65

Warranty and Product Information

Certifications
ETL, UL
Collection
Leeward
Energy Star
No
Location Rating
Damp Location
Manufacturer Warranty
30 Year Limited
